water heating pellet stove
Water heating pellet stoves are designed to heat your home or business (hotel, restaurant, hospital, etc.) through a renewable source of energy such as wood. They are highly efficient and easy to use, since their functionalities are very similar to those of oil and propane boilers, providing fully automatic operation, domestic hot water heating, and zoned comfort control systems.Wood pellets are fed from the hopper into the burner, whose output is adjusted automatically to reach the set temperature by controlling the feed rate of pellets - your stove should be refilled with pellets periodically, but it will depend on how hot you want your property, how big it is and how well insulated. The heat energy is transferred to water from the central heating system, and then circulates around the property to either radiators and/or underfloor heating.
Regarding maintenance, your pellet stove will need some cleaning about once every two months as there is very little maintenance involved, basically wood ash waste cleaning. However, this waste can be also used for fertilizing purposes.
Time to replace your old oil fired water heating system? Contact our Experts!
Water Heating Pellet Stove
Specifications:
1. Pellet stove connecting to radiator for hot water.
2. Automatic operation with remote control.
3. Rated power: 12kw, 15kw
Main Feature:
- With both hot wind blasting and hot water system.
- Connecting to radiator for more room heating.
- With remote control for operation.
- Automatic temperature operation.
- Pellet stove style with more function and convenient installation.
- Fuel for wood pellet in 6mm.
Main Data for Pellet Stove:
|
Modle N=nominal R=minimum |
GC-P12 | GC-P15 | GC-P18 | |||
|---|---|---|---|---|---|---|
| N | R | N | R | N | R | |
| Thermal Output | 12.0kw | 3.6kw | 15.0kw | 4.8kw | 18.0kw | 7.2kw |
|
Heat output transferred to room air |
3.5kw | 1.1kw | 4.5kw | 1.1kw | 5.5kw | 1.1kw |
| Heat output transferred to water | 8.5kw | 2.5kw | 10.5kw | 2.5kw | 12.5kw | 2.5kw |
| CO emission at 13% oxygen | 0.024% | 0.06% | 0.024% | 0.06% | 0.024% | 0.06% |
| Efficiency | 90% | 90% | 90% | 90% | 90% | 90% |
|
Max. allowable water pressure during operation |
2bar | 2bar | 2bar | |||
| Safety valve | 3bar | 3bar | 3bar | |||
| Max. delivery temperature | 85℃ | 85℃ | 85℃ | |||
| Nominal electrical power | 430w | 430w | 430w | |||
| Nominal voltage | 230v | 230v | 230v | |||
| Nominal frequency | 50/60Hz | 50/60Hz | 50/60Hz | |||
| Fuel | wood pellet | wood pellet | wood pellet | |||
| Fuel consumption per hour | 1.8kg/h | 0.6kg/h | 2.1kg/h | 0.8kg/h | 2.4kg/h | 1.2kg/h |
| Flue gas temperature | 100℃ | 80℃ | 100℃ | 80℃ | 100℃ | 80℃ |
| flue draught pressure | 10pa | 10pa | 10pa | 10pa | 10pa | 10pa |
| Expansion tank | 3L | 3L | 3L | |||
| Boiler capacity | 16 | 18 | 24 | |||
| Connections | 1-3/4 | 1-3/4 | 1-3/4 | |||
| Receptacle capacity | 25kg | 25kg | 40kg | |||
| Burn time | 14h | 41h | 12h | 31h | 16h | 33h |
| Operating power required | 150W | 150W | 150W | |||
| Flue gases outlet | ø80mm | ø80mm | ø80mm | |||
| Combustion air intake | ø50mm | ø50mm | ø50mm | |||
|
Weight of the structure including packing |
114kg | 120kg | 150kg | |||
| Size(w*d*h) | 522mm*54mm1*1020mm | 522mm*541mm*1020mm | 600mm*650mm*1200mm | |||
